Spring steel should have excellent overall performance, such as mechanical properties, resistance to elasticity reduction performance (that is, resistance to elasticity reduction performance, also known as resistance to relaxation performance), fatigue performance, hardenability, physical and chemical properties (heat resistance, low temperature resistance, oxidation resistance, corrosion resistance, etc.).
In order to meet the above performance requirements, spring steel has excellent metallurgical quality (high purity and uniformity), good surface quality , accurate shape and size.
Steel grade | C [%] | Si [%] | Mn [%] | P [%] max. | S [%] max. | Cr [%] max. / – | Mo [%] | Ni [%] max. | V [%] |
C55S | 0.52 – 0.60 | 0.15 – 0.35 | 0.60 – 0.90 | 0.025 | 0.010 | 0.40 | 0.10 | 0.40 | – |
C60S | 0.57 – 0.65 | 0.15 – 0.35 | 0.60 – 0.90 | 0.025 | 0.010 | 0.40 | 0.10 | 0.40 | – |
C67S | 0.65 – 0.73 | 0.15 – 0.35 | 0.60 – 0.90 | 0.025 | 0.010 | 0.40 | 0.10 | 0.40 | – |
C75S | 0.70 – 0.80 | 0.15 – 0.35 | 0.60 – 0.90 | 0.025 | 0.010 | 0.40 | 0.10 | 0.40 | – |
C100S | 0.95 – 1.05 | 0.15 – 0.35 | 0.30 – 0.60 | 0.025 | 0.010 | 0.40 | 0.10 | 0.40 | – |
51CrV4 | 0.47 – 0.55 | 0.40 | 0.70 – 1.10 | 0.025 | 0.010 | 0.90 – 1.20 | 0.10 | 0.40 | 0.10 – 0.25 |
80CrV2 | 0.75 – 0.85 | 0.15 – 0.35 | 0.30 – 0.50 | 0.025 | 0.010 | 0.40 – 0.60 | 0.10 | 0.40 | 0.15 – 0.25 |
Category | EN 47 Spring Steel |
Density: | 7.85 g/cm3 |
Thermal Expansion: | 11.2 x 10-6/°C |
Thermal Conductivity: | 43 W/m.K |
Electrical Resistivity: | 0.142 x 10-6 Ω.m |
Elastic Modulus: | 190-210 GPA |
Poisson’s Ratio: | 0.27-0.30 |
Hardness: | 30-35 HRC (Annealed condition) |
Tensile Strength: | 785-935 MPa |
Yield Strength: | 550-690 MPa |
Elongation: | 12-15% |
1, Applications include piano wire (also known as music wire) such as ASTM A228 (0.80–0.95% carbon), spring clamps, antennas, springs (e. g. vehicle coil springs or leaf springs), and s-tines.
2, Spring steel is commonly used in the manufacture of swords with rounded edges for training or stage combat, as well as sharpened swords for collectors and live combat.
3, Spring steel is one of the most popular materials used in the fabrication of lockpicks due to its pliability and resilience.
4, Tubular spring steel is used in the landing gear of some small aircraft due to its ability to absorb the impact of landing.
5, It is frequently used in the making of knives, machetes, and other edged tools.
6, It is used in electrical fish tapes.
7, It is used in binder clips.
8, Used extensively in shims due to its resistance to deformation in low thicknesses.
| sae 4140 hot rolled alloy steel plate | steel plated zinc alloy |
| scm3 alloy steel plate | t1 alloy steel plate |
| scr440 alloy steel plate | strencor minotaur 7' alloy steel chrome-plated olympic barbell bar |
| q345b s355jr high strength low alloy structural steel plate | titanium alloy steel plate |
| ss400 q235 q345 alloy steel plate | titanium zinc alloy-plated sheet steel |
| stainless steel floor plate alloy | tensile alloy steel plate factory |
| stc42 alloy steel plate | wear alloy steel plate |
| steel aluminum alloy plate | wholesale alloy structural steel plate |
We are a well known worldwide supply and export Spring steel in following countries：,Italy, Philippines, France，Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
