Abrasion resistant (AR) steel plate is a high-carbon alloy steel designed specifically to have greater hardness properties than low-carbon steel.
Hardness typically comes at the expense of strength, making AR wear-resistant steel an ideal material for harsh, high-abrasion conditions, and not for structural applications.
Abrasion resistant steel plate is extremely durable and wear-resistant, defending well against scuffs and scratches. This type of steel works well in harsh applications, and also offers some impact resistance. Wear resistant steel plate will ultimately help extend the life of your applications and reduce your costs in the long-run.
Abrasion resistant steel plate is commonly used in energy, industrial manufacturing, infrastructure, and more. Additional applications include:
1, Mining
2, Construction
3, Material Handling
Steel/Grade | C | Si | Mn | P | S | AL | Cr+Ni+Mo | Nb+V+Ti |
NM360/AR36 | 0.10-0.30 | 0.20-0.40 | 1.00-2.00 | ≤0.015 | ≤0.003 | ≥0.20 | <0.6 | Trace Amount |
NM400/AR40 | 0.10-0.40 | 0.20-0.40 | 1.00-2.00 | ≤0.015 | ≤0.003 | ≥0.20 | <0.9 | |
NM450/AR45 | 0.10-0.40 | 0.20-0.40 | 1.00-2.00 | ≤0.015 | ≤0.003 | ≥0.20 | <1.2 | |
NM500/AR50 | 0.10-0.40 | 0.20-0.45 | 1.00-2.00 | ≤0.015 | ≤0.003 | ≥0.20 | <1.5 | |
NM550/AR55 | 0.10-0.50 | 0.20-0.45 | 1.00-1.50 | ≤0.015 | ≤0.003 | ≥0.20 | <2.0 | |
NM600/AR60 | 0.10-0.50 | 0.20-0.45 | 1.00-1.50 | ≤0.015 | ≤0.003 | ≥0.20 | <2.5 |
Grade | Tensile strength | Elongation | Hardness | -20℃ Impact energy |
(Mpa) | (%)(min) | (HBW) | AKv/J (min) | |
NM360 | ≥1100 | 12 | 330-390 | 24 |
NM400 | ≥1200 | 10 | 370-430 | 24 |
NM450 | ≥1250 | 7 | 420-480 | 24 |
Product Name | Wear Resistant Steel Sheet / Wear Resistant Steel Plate |
Standard Grade | GB:NB300,NM360,NM400,NM450,NM500,NM550 ASTM:AR360,AR400F,AR400,AR500,AR500 FJIS:HARD400,HARD450,HARD500,HARD600 DIN:XAR400,XAR450,XAR500,XAR600SWE:HARDOX400,HARDOX450,HARDOX500,HARDOX600 |
Technique | Hot rolled or cold rolled |
Surface Treatment | Blasting, painting, cleaning or customized |
Length | 4m-12m for reference or customized |
Width | 0.6m-3m for reference or customized |
Thickness | 3mm-300mmfor reference or customized |
Thickness Tolerance | ±0.1mm |
Application | Widely used in a variety of architectural and engineering structures,such 1.) metal constructions such as buildings,bridges,ships; 2.) transmission tower, reaction tower; 3.) lifting transportation machinery; 4.) industrial furnace;boilers 5.) container frame, warehouse goods shelves, etc |
